L、S、C、X、Ku、K、Ka寬頻帶同軸隔離器環行器JQL Technologies

發布于：2025-10-16 14:49:45

品牌名稱：JQL

訂貨周期：6-8周
立即訂購

重要參數：

頻段：1~31GHz

隔離度：12~25dB

插入損耗：0.35~1.5dB

駐波比：1.22~1.8

產品詳情

同軸隔離器

Part Number	Band (GHz)	Bandwidth (GHz)	Isolation	Ins Loss	VSWR	Avg Power
JIC1000T2000S6R	1.000~2.000	Full	16	0.70	1.40	60/10
JIC1000T2000SFSM1	1.000~2.000		16.0	0.75		5/5/-
JIC1400T2500S1R	1.400~2.500	Full	17	0.60	1.35	60/10
JIC1425T2690S1R	1.425~2.690	Full	17	0.60	1.35	60/10
JIC1500T2200SMSF1	1.500~2.200	Full	21	0.35	1.19	10/10
JIC1500T2500S10	1.500~2.500	Full	20	0.50	1.22	20/10
JIC1700T2600SFSM1	1.700~2.600	Full	19	0.60	1.25	20/10
JIC2000T4000S1R	2.000~4.000	Full	18	0.50	1.30	30/2
JIC2000T8000S1	2.000~8.000	Full	12	1.50	1.80	30/10
JIC2500T3500S2	2.500~3.500	Full	20	0.60	1.22	20/20
JIC3000T5000S1	3.000~5.000	Full	19.0	0.50	1.25	25/1/-
JIC3000T6000S1R	3.000~6.000	Full	17	0.60	1.4	30/10
JIC4000T8000S1R	4.000~8.000	Full	20	0.40	1.25	30/2
JIC4000T8000SFSM1	4.000~8.000		18.0	0.40		30/10/-
JIC5900T10K6S1R	5.900~10.60	Full	20	0.50	1.25	10/1
JIC6000T12K0S1D	6.000~12.00	Full	16	0.60	1.40	10/10
JIC6000T18K0S1	6.000~18.00	Full	12	1.50	1.8	15/10
JIC6000T12K0S1D-Ver2	6.000~12.000	Full	16	0.6		10/10/30
JIC7000T11K0S1R	7.000~11.00	Full	20	0.40	1.25	10/10
JIC8000T12K4S1R	8.000~12.40	Full	20	0.40	1.25	10/2
JIC8000T16K0S1	8.000~16.00	Full	17	0.80	1.4	15/10
JIC8000T18K0S1	8.000~18.00	Full	17	0.80	1.4	15/10
JIC8000T16K0S1-Ver2	8.000~16.00	Full	17.0	0.6		30/-
JIC8000T18K0SFSM1	8.000~18.000		15.0	0.95		30/10/-
JIC9700T12K5SMSF1	9.700~12.50	Full	20	0.50	1.22	1/1
JIC12K0T15K0S1R	12.00~15.00	Full	20	0.40	1.22	10/10
JIC12K0T18K0S1R	12.00~18.00	Full	20	0.60	1.30	10/10
JIC12K7T14K8SMSF0	12.700~14.800		20.0	0.45		1/1/-
JIC15K1T22K0K1	15.10~22.00	Full	18	0.70	1.19	10/2
JIC17K0T22K0K1	17.00~22.00	Full	20	0.50	1.25	10/2
JIC17K2T18K2SMSF0	17.20~18.20		20.0	0.500.40		1/1/-
JIC27K0T31K0K0	27.00~31.00	Full	19	0.70	1.25	2/1

同軸環形器

Part Number	Band (GHz)	Bandwidth (GHz)	Isolation	Ins Loss	VSWR	Avg Power
JCC1000T2000S6	1.000~2.000	Full	16.0	0.7	1.4	60
JCC1000T2000N10	1.000~2.000	Full	16.0	0.70
JCC1350T2700S2	1.350~2.700	Full	17	0.6	1.35	20
JCC1460T1960N10	1.460~1.960	Full	25	0.4	1.22	100
JCC1485T2130S10	1.485~2.130	Full	19	0.4	1.25	100
JCC1500T2500S2	1.500~2.500	Full	20	0.5	1.22	25
JCC1500T2000N20	1.500~2.000	Full	19	0.35	1.25	200
JCC1600T3000S1	1.600~3.000	Full	15.0	0.6	1.43	10
JCC1800T3000N25-Ver2	1.800~3.000	Full	19.0	0.50
JCC2000T4000S3R	2.000~4.000	Full	18.0	0.5	1.3	60
JCC2000T4000N6R	2.000~4.000	Full	18	0.5	1.3	60
JCC2000T4800S1R3	2.000~4.800	Full	11.0	0.6	1.78	10
JCC2000T4000NF25	2.000~4.000	Full	15	0.6	1.45	250
JCC3000T6000S1R	3.000~6.000	Full	20.0	0.60	1.4	30
JCC3000T6000NF20	3.000~6.000	Full	18.0	0.5
JC2C3300T5675S1R	3.300~5.675	Full	2~1@42; 4~3@42 \|\| 3~2@20; 1~4@20	1~2@0.9; 3~4@0.9 \|\| 2~3@0.5; 4~1@0.5
JCC4000T8000S1R	4.000~8.000	Full	18.0	0.4	1.25
JCC4000T8000NF15	4.000~8.000	Full	15	0.6	1.42	150
JCC5000T8000NMNFNF1	5.000~8.000	Full	19.0	0.45
JCC6000T12K0S1D	6.000~12.00	Full	16	0.60	1.37	10
JCC6000T12K4S2	6.000~12.40	Full	16	0.6	1.4	10
JCC6000T18K0S1	6.000~18.00	Full	12	1.50	20	10
JCC7000T11K0S1R	7.000~11.00	Full	20.0	0.5	1.25	25
JCC8000T18K0S1	8.000~18.00	Full	16	0.80	1.50	10
JCC8000T18K0S15	8.000~18.00	Full	13	1.3	1.57	150
JCC16K0T22K0S2	16.00~22.00	Full	18.0	0.50	1.3	10
JCC22K0T28K0K0	22.00~28.00	Full	18	1.2	1.25	1
JCC22K0T27K0K1	22.00~27.00	Full	18.0	0.6

上一個: 17-40GHz同軸隔離器環行器JQL Technologies

下一個: L、S、C、X、Ku波段寬頻帶嵌入式隔離器環行器
